Explore Details
The AL-800 Digital Auto Lensmeter is designed for fast and accurate lens measurement in optical shops, clinics, and lens processing laboratories. It supports automatic recognition of single vision, bifocal, progressive, and contact lenses, helping improve daily workflow and measurement efficiency.
With a 7-inch HD touch LCD and Hartmann multi-point measurement system, the AL-800 provides stable readings for sphere, cylinder, axis, prism, and ADD values. It also supports UV and blue light transmittance testing, making it suitable for modern optical inspection and lens verification.
Measurement Functions：
- Refraction (sphere, cylinder, axis)
- Visual balance testing
- Heterophoria evaluation
- Binocular vision and stereoscopic vision testing
- Accommodation and fusion function assessment
Specifications
| Sphere powers range | ±16.75Dto-19.00D,with minimum reading 0.25D or 0.12D |
| (when 0.12D auxiliary lens or optional±0.12D lens is in use) | |
| Cylinder powers range | 0 to-6.00D,with minimum reading 0.25Dor0.12D |
| ( when auxiliary lens is in use) 0 to-8.00D | |
| ( when-2.00D auxiliary lens is in use) | |
| Astigmatic axis scale | 0 to 180°in 5°steps |
| Cross Cylinder | reversal type (synchronized with astigmatic axis) ±0.25D,or±0.50D |
| Rotary prism | 0 to20△D in 1△D steps |
| P.D. adjustment | 48-80mm;Step:1mm |
| Forehead rest adjustment | 16mm forward and backward |
| Convergence | The optical axes 0g thelenses are aligned at a diatance of 400mm from the vertexes of the corneas (2mm each for right and left inward)Interpupillary distance enabling convergence=57mm to 80mm |
| Corneal distance device | 2mm forward and 5mm backward from standard plane;with scale |
| Effective field of view | 19mm |
| Weight | 5kgs |
| Size | 291-323mm×315mm×85mm |
